Product of the Month

Unique Boomerang feature automatically creates and emails PDF datareport when logger is connected to PC.

The MicroLite DataSuite is an advanced windows software companion for your Microlite Dataloggers. Quickly configure, download and analyze your data, or setup more advanced features to automate reports and dispatch of you data via email!

Datalogger with built in USB connector
• 16 bit resolution
• 4 digit LCD display
• Robust – IP68 Waterproof construction
• Accurate and reliable data
• Low running cost (uses a CR2032 battery)
• Free feature rich software program including automatic reporting and ‘Boomerang feature’

Data Sheet | Details | Quote Request

RF ICs

AXSEM produces a wide range of RF transceivers/receivers/transmitters which are commonly used in the bands below 1 GHz. AXSEM transceivers are known for excellent sensitivity and very efficient power amplifiers. Typical sensitivities are in the range of -110 dBm to -126 dBm for 1.2 kbps (narrow-band or general-purpose). Depending on the IC the maximum output power is between 14 dBm and 20 dBm. As AXSEM RF transceivers have integrated RX/TX switches the matching networks are simple. Customers all over the world use AXSEM RF and wireless IC for various applications including automatic meter reading, sensor networks, audio transmission and others.

Data Sheet | View Specs

The ProBee-ZS10 is a ZigBee RS232 Serial Adapter (RS232 Dongle) with integrated ZigBee core and radio/antenna circuits.

The ZS10 Serial Adapter is designed to meet specific requirements to low cost and low power wireless applications such as Home Automation, Smart Energy, Health care, Building Automation and Telecom Services by adopting the ZigBee technology.

Despite of its cost effective and low power consumptions, the ZS10 provides high performance and robust data transfer capability for wide range of applications. The ZS10 can transfer data at up to 250 kbps and reach up to 1.6 km (1 mile) outdoor line-of-sight.

Data Sheet | View Specs & Buy Online | Price: $74.00 ea.

The special HX1 transmitter modules offer a 300mW RF output VHF data link in Radiometrix SIL standard pin-out and footprint. This makes the HX1 ideally suited to those low power applications where existing narrow band and wideband transmitters provide insufficient range. Together with the matching RX1 or BiM1R receiver a one-way radio data link can be achieved over a distance up to 10km+ with suitable choice of data rate and antennas.

Frequency

144.390MHz, 144.800MHz, 145.175, 151.300MHz & 169MHz band

Details

The NRX1 is a VHF radio data receiver and it offers a low power, reliable data link in a Radiometrix SIL standard pin out and foot print. It is an enhanced, low cost version of the Radiometrix RX1, but in a slightly larger dimension.

NRX1 is compatible with the TX1 series of transmitters, and the BiM1 transceiver.

Details

The following application notes explain why VHF Narrow Band FM modules will provide significantly longer operating range than Wide Band UHF.

- Apnt005.pdf

- Choice-of-frequency-band-can-really-make-a-difference.pdf

 - Narrowband.pdf
